CLICK HERE to see photos of how coin motors have been mounted in products.
| Summary Of Specifications | |
| Technology Type: | BLDC |
| Diameter (mm): | 6.0 |
| Thickness (mm): | 2.5 |
| Rated Voltage (Vdc): | 3.0 |
| Operating Voltage (Vdc): | 2.7~3.3 |
| Rated Current MAX (mA): | 90 |
| Typical Current (mA): | 67 |
| Rise Time (ms) MAX *: | 70 |
| Fall Time (ms) MAX *: | 90 |
| Rated Speed (rpm, MIN): | 12000 |
| Vibration Force (Grms): | 0.55 |
| * at 50% of Maximum G force | |
| Packaging Spec | |
| Part Packaging: | Tray |
| Qty per reel / tray: | 100 |
| Quantity - Master box: | 4000 |
| Size - Master Box: | Call us |
| Weight - Master Box: | Call us |
| ECCN: | EAR99 |
| USA HTS TARIFF: | 8501.10.4040 |
| 25% Exclusion Code: | None |
| 25% Ex. Code Valid: | None |
|
If you need samples, please Contact Us. |
|||
|
This part is not authorized for Life Supporting Devices
None of the products offered for sale by us are authorized for use in any device that:
