The VW0518AB001D is the smallest BLDC coin vibration motor on the market. It has a low G force of 0.20 ( 30 gram sled) which will limit its applications to very light weight wearables such as smart rings and light weight wearables etc. FPC contact pads are design to mate with contact springs. We can also fabricate a custom FPC as per your design. Double stick tape on the bottom of the case facilitates mounting. A driver IC is built imbedded within the coin motor. No external driver IC is required. Voltage polarity must be observed or you will damage the internal driver IC. This device operates on DC voltage only. A PWM signal can not be used to drive BLDC motors. For MOQ: 10K pcs a custom FPC can be fabricated.
CLICK HERE to see photos of how coin motors have been mounted in products.
| Summary Of Specifications | |
| Technology Type: | BLDC |
| Diameter (mm): | 5.0 |
| Thickness (mm): | 1.85 |
| Rated Voltage (Vdc): | 3.0 |
| Operating Voltage (Vdc): | 2.7~3.3 |
| Rated Current MAX (mA): | 90 |
| Typical Current (mA): | 74 |
| Rise Time (ms) MAX *: | 70 |
| Fall Time (ms) MAX *: | 90 |
| Rated Speed (rpm): | 12500 |
| Vibration Force (Grms): | 0.05 |
| * at 50% of Maximum G force | |
| Packaging Spec | |
| Part Packaging: | Tray |
| Qty per reel / tray: | 100 |
| Quantity - Master box: | 4000 |
| Size - Master Box: | Call us |
| Weight - Master Box: | Call us |
| ECCN: | EAR99 |
| USA HTS TARIFF: | 8501.10.4040 |
| 25% Exclusion Code: | 9903.88.69 |
| 25% Ex. Code Valid: | from June 15, 2024 thru May 31, 2025 |
|
If you need samples, please Contact Us. |
|||
|
This part is not authorized for Life Supporting Devices
