The VZ3TL2B3120033P is an amazing combination of small size and low current. Ideal for wearables with limited battery capacity. At 3.2 mm it is the smallest diameter motor we make. This motor is also available with a rubber gasket that help facilitate mounting in a molded pocket, and mitigate unwanted mechanical noise when the motor is actuated. It is available in custom lead lengths as short as 8 mm. Connectorization is also possible for MOQ: 2000
| Summary Of Specifications | |
| Diameter/Height (mm): | 3.2 / 3.2 |
| Body (mm): | 8.15 |
| Overall (mm): | 12.85 |
| Rated Voltage (Vdc): | 3.0 |
| Operating Voltage (Vdc): | 2.5~3.6 |
| Rated Current MAX (mA): | 16 |
| Typical Current (mA): | 12 |
| Rated Speed (rpm): | 8500 |
| Vibration Force (Grms): | 0.50 |
| Packaging Spec | |
| Part Packaging: | Tray |
| Qty per reel / tray: | 100 |
| Quantity - Master box: | 4000 |
| Size - Master Box: | Call us |
| Weight - Master Box: | Call us |
| ECCN: | EAR99 |
| USA HTS TARIFF: | 8501.10.4060 |
| 25% Exclusion Code: | 9903.88.67 |
| 25% Ex. Code Valid: | thru May 31 2024 |
|
If you need samples, please Contact Us. |
|||
|
This part is not authorized for Life Supporting Devices
