Vybronics - one of largest suppliers of cylindrical & coin vibration motors
all cylindrical left side Table of All Cylindrical Vibrator Motors all cylindrical right side

Below is a table of the most common types of ERM cylindrical vibration motors we manufacture. Data sheets may be viewed by clicking on the part number in the left column.   3D CAD files maybe downloaded from here as well.

Prices are primarily determined by the diameter of the body. Generally speaking, our 6mm diameter types are the lowest cost, followed by 4mm diameter which are approximately 10% higher in price. Our 7mm diameter vibration motors are approx. 20% higher than our 4mm types. Our low current consumption vibration motors ( current highlighted in RED) are priced at approximately  2 to 3 times higher in than the equivalent standard current version. Connectors and rubber sleeves / boots may be added to most leaded parts. Contact us for quote.

One important factor to consider when selecting a vibration motor is how it will be mounted inside of your device. All available mounting configurations may be viewed by going to the BOTTOM of this page. After determining what configuration type(s) might work best for your application, the table below, may be sorted by “Config Type”, or any other parameter, by clicking on the top of the associated column.

Scroll To See All Motors


Part Number

Download Icon
Old P/N
(see PCN)

motor logo
Config. Type Motor Size (mm) Voltage (Vdc) Current (mA) Rated speed (rpm) Vibe Force (Grms) CLICK
to
BUY
from
Digikey image
Dia / Hgt Body
Length
Overall
Length
Rated Operating Rated
MAX
Typical*
Avg.
VJP08-74D160A JP08-74D160A VJP08-74D160A cylindrical vibration motor preview image 1.1/1.2 8.0 / 6.0 14.5 21.3 4.5 1.5~6.0 230 210 14000 4.80
QTY IN STOCK: 0
VJP10-35C270M2 VJP10-35C270M2 cylindrical vibration motor preview image 1.1/1.2 10.0 / 8.0 12.5 16.9 4.8 3.0~6.0 175 126 16000 2.60
QTY IN STOCK: 5,912
VJP12-25F190 JP12-25F190 VJP12-25F190 cylindrical vibration motor preview image 1.1/1.2 12.0 / 10.0 12.0 19.0 3.0 2.0~6.0 350 280 10000 6.00
QTY IN STOCK: 4,452
VJP12-95J100U VJP12-95J100U cylindrical vibration motor preview image 1.1/1.2 12.0 / 10.0 20.0 28.0 3.0 1.5~4.2 240 200 9600 4.80
VJP16-70E310 JP16-70E310 VJP16-70E310 cylindrical vibration motor preview image 1.1/1.2 15.5 / 12.0 18.6 27.1 7.2 2.5~7.5 180 153 8400 6.40
QTY IN STOCK: 0
VJQ24-35E400C JQ24-35E400C VJQ24-35E400C cylindrical vibration motor preview image 1.1/1.2 24.4 13.0 25.0 5.0 4.0~8.0 120 69 5100 1.50
VJQ24-35F580C JQ24-35F580C VJQ24-35F580C cylindrical vibration motor preview image 1.1/1.2 24.4 13.0 25.0 5.0 4.0~8.0 150 93 2550 3.30
QTY IN STOCK: 1,933
VJQ24-35K270B JQ24-35K270B VJQ24-35K270B cylindrical vibration motor preview image 1.1/1.2 24.4 13.0 25.0 5.0 4.0~8.0 650 550 3600 8.40
QTY IN STOCK: 4,709
VZ30C1B839981A Z30C1B839981A VZ30C1B839981A cylindrical vibration motor preview image 7 3.35 6.95 12.5 3.0 2.3~3.6 85 76 12000 0.45
QTY IN STOCK: 1,279
VZ30C1T8219731 Z30C1T8219731 VZ30C1T8219731 cylindrical vibration motor preview image 15 3.4 6.7 11.0 2.7 2.3~3.2 85 67 14000 0.42
QTY IN STOCK: 0
VZ30C1T8219732L Z30C1T8219732L VZ30C1T8219732L cylindrical vibration motor preview image 15 3.4 6.55 11.0 2.7 2.3~3.2 75 57 14000 0.42
QTY IN STOCK: 10,559
VZ30C1T8460002L Z30C1T8460002L VZ30C1T8460002L cylindrical vibration motor preview image 15 3.0 6.8 10.8 2.7 2.3~3.2 85 67 15000 0.39
QTY IN STOCK: 44,284
VZ30C1T9870088L Z30C1T9870088L VZ30C1T9870088L cylindrical vibration motor preview image 15 3.5 5.9 12.7 2.3 2.1~3.2 130 107 8500 0.70
QTY IN STOCK: 1,163
VZ30L4B8790008L Z30L4B8790008L VZ30L4B8790008L cylindrical vibration motor preview image 1 3.15 6.55 10.8 3.0 2.3~3.7 80 58 14000 0.50
QTY IN STOCK: 445
VZ30L4B8790698L Z30L4B8790698L VZ30L4B8790698L cylindrical vibration motor preview image 17 3.6 7.00 10.8 3.0 2.3~3.7 80 58 14000 0.50
QTY IN STOCK: 2,399
VZ3TH5B0640081P VZ3TH5B0640081P cylindrical vibration motor preview image 5 3.2 / 4.2 8.4 12.3 3.0 2.5~3.6 80 67 10500 0.75
VZ3TH5B3120066P VZ3TH5B3120066P cylindrical vibration motor preview image 5 3.2 / 4.2 8.4 13.1 3.0 2.5~3.6  40 27 12000 0.60
VZ3TH5B3120076P
blinking new image
VZ3TH5B3120076P cylindrical vibration motor preview image 5 3.2 / 4.2 8.4 13.1 3.0 2.5~3.6  16 12 8500 0.50
VZ3TH8B171700L Z3TH8B171700L VZ3TH8B171700L cylindrical vibration motor preview image 5 2.5 / 2.9 6.6 11.0 2.7 2.3~3.3 100 77 13000 0.40
QTY IN STOCK: 429
VZ3TL2B3120033P
blinking new image
VZ3TL2B3120033P cylindrical vibration motor preview image 1 3.2 / 3.2 8.15 12.85 3.0 2.5~3.6  16 12 8500 0.50
VZ3TL2B3120034P
blinking new image
VZ3TL2B3120034P cylindrical vibration motor preview image 17 3.2 / 3.8 8.5 13.2 3.0 2.5~3.6  16 12 8500 0.50
VZ3TL5B0640080P VZ3TL5B0640080P cylindrical vibration motor preview image 17 3.2 / 3.8 8.5 12.4 3.0 2.5~3.6 80 67 10500 0.75
VZ3TL5B3120060P VZ3TL5B3120060P cylindrical vibration motor preview image 1 3.2 / 3.2 8.15 12.85 3.0 2.5~3.6  40 27 12000 0.60
VZ3TL5B3120061P VZ3TL5B3120061P cylindrical vibration motor preview image 17 3.2 / 3.8 8.5 13.2 3.0 2.5~3.6  40 27 12000 0.60
VZ43FC1A6730098U VZ43FC1A6730098U cylindrical vibration motor preview image 15 4.85 10.4 15.5 1.3 1.1~1.7 105 94 9000 0.90
QTY IN STOCK: 658
VZ43FC1B5640005L Z43FC1B5640005L VZ43FC1B5640005L cylindrical vibration motor preview image 15 4.3 5.5 12.0 1.3 1.3~1.6 120 87 9000 0.60
QTY IN STOCK: 62,280
VZ43FC1B5640007L Z43FC1B5640007L VZ43FC1B5640007L cylindrical vibration motor preview image 15 4.3 7.5 12.0 3.0 2.5~3.4 100 77 10000 0.65
QTY IN STOCK: 6,506
VZ43FM1B8230001L Z43FM1B8230001L VZ43FM1B8230001L cylindrical vibration motor preview image 15 3.4 6.55 12 3.0 2.3~3.6 85 67 12000 0.60
QTY IN STOCK: 4,173
VZ4FC1B0951788U VZ4FC1B0951788U cylindrical vibration motor preview image 15 4.85 7.2 11.0 3.0 2.6~3.6 105 90 10000 0.70
VZ4FC1B1301781 Z4FC1B1301781 VZ4FC1B1301781 cylindrical vibration motor preview image 15 4.85 7.2 10.9 3.0 2.6~3.6 110 87 10000 0.70
QTY IN STOCK: 0
VZ4KC1B1051202 Z4KC1B1051202 VZ4KC1B1051202 cylindrical vibration motor preview image 4 4.0 11.3 15.6 3.0 2.2~3.6 70 42 14000 1.20
QTY IN STOCK: 559
VZ4KH1A0031121 Z4KH1A0031121 VZ4KH1A0031121 cylindrical vibration motor preview image 5 4.0 / 5.9 11.4 16.6 1.3 1.1~1.6 85 57 8500 0.85
VZ4KH2B0470653N Z4KH2B0470653N VZ4KH2B0470653N cylindrical vibration motor preview image 5 4.0 / 5.95 11.4 16.2 3.0 2.2~3.6 75 56 11000 1.55
QTY IN STOCK: 0
VZ4KL2A0030001 Z4KL2A0030001 VZ4KL2A0030001 cylindrical vibration motor preview image 1 4.0 11.0 15.8 1.3 1.1~1.6 85 57 8500 0.85
VZ4KL2A0280001 Z4KL2A0280001 VZ4KL2A0280001 cylindrical vibration motor preview image 1 4.0 11.0 16.9 1.3 1.1~1.6 80 56 10000 0.65
VZ4KL2B0030001 Z4KL2B0030001 VZ4KL2B0030001 cylindrical vibration motor preview image 1 4.0 11.0 15.8 3.0 2.2~3.6 70 52 10500 1.15
VZ4KL2B0030471 Z4KL2B0030471 VZ4KL2B0030471 cylindrical vibration motor preview image 17 4.0 / 5.0 11.8 16.6 3.0 2.2~3.6 70 53 10500 1.30
QTY IN STOCK: 967
VZ4KL2B0280001 Z4KL2B0280001 VZ4KL2B0280001 cylindrical vibration motor preview image 1 4.0 11.0 16.9 3.0 2.2~3.6 70 50 12000 1.05
VZ4KL2B0780012P Z4KL2B0780012P VZ4KL2B0780012P cylindrical vibration motor preview image 17 4.0 / 4.6 11.2 17.0 3.0 2.5~3.6  23 18 7000 0.80
VZ4SH2B0071097N 5 4.0 / 5.8 10.4 14.7 3.0 2.2~3.6 70 45 10000 1.25
VZ4SL2A0270001 Z4SL2A0270001 VZ4SL2A0270001 cylindrical vibration motor preview image 1 4.0 10.0 14.8 1.3 1.1~1.6 80 59 11000 0.65
VZ4SL2A0280001 Z4SL2A0280001 VZ4SL2A0280001 cylindrical vibration motor preview image 1 4.0 10.0 15.9 1.3 1.1~1.6 90 57 9500 0.65
VZ4SL2A0280131 Z4SL2A0280131 VZ4SL2A0280131 cylindrical vibration motor preview image 2 4.0 10.0 15.9 1.3 1.1~1.6 85 57 10000 0.65
VZ4SL2B0270131 Z4SL2B0270131 VZ4SL2B0270131 cylindrical vibration motor preview image 2 4.0 10.0 14.8 3.0 2.2~3.6 60 47 14000 0.70
VZ4SL2B0280001 Z4SL2B0280001 VZ4SL2B0280001 cylindrical vibration motor preview image 1 4.0 10.0 15.9 3.0 2.2~3.6 70 46 12000 1.85
VZ4SL2B0280131 Z4SL2B0280131 VZ4SL2B0280131 cylindrical vibration motor preview image 2 4.0 10.0 15.9 3.0 2.2~3.6 70 50 12000 0.55
VZ4TC2B0640001P Z4TC2B0640001P VZ4TC2B0640001P cylindrical vibration motor preview image 1 4.0 / 4.0 5.5 9.3 3.0 2.4~3.6  22 19 8000 0.40
VZ4TC2B0640002P Z4TC2B0640002P VZ4TC2B0640002P cylindrical vibration motor preview image 17 4.0 / 4.6 5.8 9.6 3.0 2.4~3.6  22 19 8000 0.40
VZ4TC2B0640007P VZ4TC2B0640007P cylindrical vibration motor preview image 6 4.0 / 5.0 5.8 9.6 3.0 2.4~3.6  22 19 8000 0.25
VZ4TH1B0611160L Z4TH1B0611160L VZ4TH1B0611160L cylindrical vibration motor preview image 6 4.0 / 5.8 9.0 13.2 3.0 2.4~3.6 100 80 11000 1.00
QTY IN STOCK: 1,812
VZ4TH2B0370078L Z4TH2B0370078L VZ4TH2B0370078L cylindrical vibration motor preview image 5 4.0 / 4.5 8.6 12.3 3.0 2.4~3.6  30 20 10000 0.70
VZ4TH5B0191760L Z4TH5B0191760L VZ4TH5B0191760L cylindrical vibration motor preview image 5 4.0 / 4.5 8.6 11.6 3.0 2.4~3.6 85 55 14000 0.80
QTY IN STOCK: 916
VZ4TH5B1241993L Z4TH5B1241993L VZ4TH5B1241993L cylindrical vibration motor preview image 5 4.0 / 4.9 8.7 11.9 3.0 2.4~3.6 85 55 14000 0.80
QTY IN STOCK: 1,642
VZ4TH5B1462252 Z4TH5B1462252 VZ4TH5B1462252 cylindrical vibration motor preview image 5 4.0 / 4.9 8.7 12.7 3.0 2.2~3.6  30 21 13000 0.40
VZ4TH5B1462253L Z4TH5B1462253L VZ4TH5B1462253L cylindrical vibration motor preview image 5 4.0 / 4.8 8.7 12.7 3.0 2.4~3.6  30 17 13000 0.70
VZ4TH5B1709181L Z4TH5B1709181L VZ4TH5B1709181L cylindrical vibration motor preview image 5 4.0 / 5.5 8.9 13.4 3.0 2.4~3.6 110 84 10000 1.10
QTY IN STOCK: 1,506
VZ4TH7B2120042P Z4TH7B2120042P VZ4TH7B2120042P cylindrical vibration motor preview image 6 4.0 / 5.0 8.5 12.3 3.0 2.4~3.6  12 9 8000 0.45
QTY IN STOCK: 626
VZ4TJ1B0370011L Z4TJ1B0370011L VZ4TJ1B0370011L cylindrical vibration motor preview image 1.1 4.0 / 5.0 8.2 12.2 3.0 2.4~3.6 95 67 14000 0.80
VZ4TL2B0020001 Z4TL2B0020001 VZ4TL2B0020001 cylindrical vibration motor preview image 1 4.0 8.0 12.1 3.0 2.2~3.6 100 73 12000 1.25
VZ4TL2B0020011 Z4TL2B0020011 VZ4TL2B0020011 cylindrical vibration motor preview image 17 4.0 / 5.0 8.0 12.8 3.0 2.2~3.6 100 84 12000 1.00
VZ4TL2B0370032L 1 4.0 / 4.0 8.2 12.1 3.0 2.4~3.6  30 20 10000 0.70
VZ4TL2B0370055L Z4TL2B0370055L VZ4TL2B0370055L cylindrical vibration motor preview image 17 4.0 / 4.5 8.2 12.1 3.0 2.4~3.6  30 20 10000 0.70
QTY IN STOCK: 174
VZ4TL2B0620043P Z4TL2B0620043P VZ4TL2B0620043P cylindrical vibration motor preview image 1 4.0 / 4.0 8.2 12.8 3.0 2.4~3.6  12 9 8000 0.45
VZ4TL2B0620044P Z4TL2B0620044P VZ4TL2B0620044P cylindrical vibration motor preview image 17 4.0 / 4.7 8.2 12.8 3.0 2.4~3.6  12 9 8000 0.45
QTY IN STOCK: 526
VZ4TL2B124064X Z4TL2B124064X VZ4TL2B124064X cylindrical vibration motor preview image 17 4.0 / 4.6 8.6 11.6 3.0 2.2~3.6 80 56 15000 1.30
QTY IN STOCK: 1,262
VZ6CC3A0540001 Z6CC3A0540001 VZ6CC3A0540001 cylindrical vibration motor preview image 11.1 6.0 15.2 20.2 1.3 1.1~1.6 70 43 8500 1.00
VZ6CH1A0082352 Z6CH1A0082352 VZ6CH1A0082352 cylindrical vibration motor preview image 5 6.0 / 8.05 15.3 20.8 1.3 0.9~1.6 80 67 7500 1.10
VZ6CL2A0080001 Z6CL2A0080001 VZ6CL2A0080001 cylindrical vibration motor preview image 1 6.0 15.0 20.6 1.3 0.9~1.6 80 67 7500 1.10
VZ6CL2A0080491 Z6CL2A0080491 VZ6CL2A0080491 cylindrical vibration motor preview image 3 6.0 15.0 20.5 1.3 0.9~1.6 80 67 7500 1.10
VZ6CL2A0540722 Z6CL2A0540722 VZ6CL2A0540722 cylindrical vibration motor preview image 9 6.0 15.0 21.9 1.3 0.9~1.6 70 43 8500 1.00
VZ6DC1A0050091 Z6DC1A0050091 VZ6DC1A0050091 cylindrical vibration motor preview image 4 6.0 12.3 17.3 1.3 0.9~1.6 85 67 8500 0.80
VZ6DC1B0050091 Z6DC1B0050091 VZ6DC1B0050091 cylindrical vibration motor preview image 4 6.0 12.3 17.3 3.0 2.2~3.6 70 57 11000 1.10
VZ6DC1B0730091 Z6DC1B0730091 VZ6DC1B0730091 cylindrical vibration motor preview image 4 6.0 12.3 18.8 3.0 2.2~3.6 90 62 7000 1.30
VZ6DCBB0056091 Z6DCBB0056091 VZ6DCBB0056091 cylindrical vibration motor preview image 4 6.0 12.3 17.3 3.0 2.2~3.6 70 57 11000 1.10
QTY IN STOCK: 901
VZ6DCBB0735091 Z6DCBB0735091 VZ6DCBB0735091 cylindrical vibration motor preview image 4 6.0 12.3 18.8 3.0 2.2~3.6 90 62 7000 1.30
QTY IN STOCK: 10,941
VZ6DH2B1501851 Z6DH2B1501851 VZ6DH2B1501851 cylindrical vibration motor preview image 5 6.0 / 7.2 13.1 17.8 3.0 2.2~3.6 75 53 11000 1.20
QTY IN STOCK: 0
VZ6DH2B1501852 Z6DH2B1501852 VZ6DH2B1501852 cylindrical vibration motor preview image 5 6.0 / 7.2 13.1 17.8 3.0 2.0~3.6  40 23 9500 1.00
VZ6DL2A0050001 Z6DL2A0050001 VZ6DL2A0050001 cylindrical vibration motor preview image 1 6.0 12.0 17.1 1.3 0.9~1.6 85 67 8500 0.80
VZ6DL2A0050441 Z6DL2A0050441 VZ6DL2A0050441 cylindrical vibration motor preview image 2 6.0 12.0 17.1 1.3 0.9~1.6 85 67 8500 0.80
VZ6DL2A0170001 Z6DL2A0170001 VZ6DL2A0170001 cylindrical vibration motor preview image 1 6.0 12.0 17.3 1.3 0.9~1.6 100 72 7000 0.95
VZ6DL2A0170441 Z6DL2A0170441 VZ6DL2A0170441 cylindrical vibration motor preview image 2 6.0 12.0 17.3 1.3 0.9~1.6 100 72 7000 0.95
VZ6DL2A0765217 Z6DL2A0765217 VZ6DL2A0765217 cylindrical vibration motor preview image 9.1 6.0 12.0 24.5 1.3 0.9~1.6 250 175 10000 2.60
VZ6DL2B0050001 Z6DL2B0050001 VZ6DL2B0050001 cylindrical vibration motor preview image 1 6.0 12.0 17.1 3.0 2.2~3.6 70 57 11000 1.10
VZ6DL2B0050441 Z6DL2B0050441 VZ6DL2B0050441 cylindrical vibration motor preview image 2 6.0 12.0 17.1 3.0 2.0~3.8 70 57 11000 1.10
VZ6DL2B0055211 Z6DL2B0055211 VZ6DL2B0055211 cylindrical vibration motor preview image 9.1 6.0 12.0 24.5 3.0 2.2~3.6 70 57 11000 1.10
QTY IN STOCK: 1,057
VZ6DL2B0170001 Z6DL2B0170001 VZ6DL2B0170001 cylindrical vibration motor preview image 1 6.0 12.0 17.4 3.0 2.2~3.6 85 53 8000 1.80
VZ6DL2B0541192 Z6DL2B0541192 VZ6DL2B0541192 cylindrical vibration motor preview image 17 6.0 / 6.7 12.4 17.4 3.0 2.2~3.6 90 67 11000 2.40
QTY IN STOCK: 887
VZ6DL2B1501193 Z6DL2B1501193 VZ6DL2B1501193 cylindrical vibration motor preview image 17 6.0 / 6.7 12.4 17.0 3.0 2.0~3.6  40 26 9500 1.00
VZ6DL2H0125215 Z6DL2H0125215 VZ6DL2H0125215 cylindrical vibration motor preview image 9.1 6.0 12.0 24.5 1.5 1.0~1.8 80 35 10200 0.80
VZ6GL2A0050461 Z6GL2A0050461 VZ6GL2A0050461 cylindrical vibration motor preview image 3 6.0 13.5 18.6 1.3 0.9~1.6 70 48 8000 1.00
VZ6SC0A0060081 Z6SC0A0060081 VZ6SC0A0060081 cylindrical vibration motor preview image 4 6.0 10.3 14.4 1.3 0.9~1.6 90 68 8500 0.80
QTY IN STOCK: 915
VZ6SC0A0150081 Z6SC0A0150081 VZ6SC0A0150081 cylindrical vibration motor preview image 4 6.0 10.3 14.0 1.3 0.9~1.6 80 65 9000 0.65
VZ6SC0B0060081 Z6SC0B0060081 VZ6SC0B0060081 cylindrical vibration motor preview image 4 6.0 10.3 14.4 3.0 2.2~3.6 70 52 10000 1.10
QTY IN STOCK: 4,006
VZ6SC0B0150081 Z6SC0B0150081 VZ6SC0B0150081 cylindrical vibration motor preview image 4 6.0 10.3 14.0 3.0 2.2~3.6 70 45 10000 1.25
VZ6SC0B0170081 Z6SC0B0170081 VZ6SC0B0170081 cylindrical vibration motor preview image 4 6.0 10.3 15.7 3.0 2.2~3.6 75 48 8000 1.25
VZ6SC3A0060001 Z6SC3A0060001 VZ6SC3A0060001 cylindrical vibration motor preview image 11.1 6.0 10.2 14.3 1.3 0.9~1.6 90 68 8500 0.70
VZ6SCAA0061141 Z6SCAA0061141 VZ6SCAA0061141 cylindrical vibration motor preview image 4 6.0 10.3 14.4 1.3 0.9~1.6 90 68 8500 0.70
VZ6SCAB0061141 Z6SCAB0061141 VZ6SCAB0061141 cylindrical vibration motor preview image 4 6.0 10.3 14.4 3.0 2.2~3.6 70 52 10000 1.10
QTY IN STOCK: 5,424
VZ6SCAB0171141 VZ6SCAB0171141 cylindrical vibration motor preview image 4 6.0 10.3 15.6 3.0 2.2~3.6 75 48 8000 1.25
VZ6SCAB0761141
blinking new image
VZ6SCAB0761141 cylindrical vibration motor preview image 4 6.0 10.3 16.4 3.0 2.2~3.6 160 120 12000 1.70
VZ6SH1A0060711 Z6SH1A0060711 VZ6SH1A0060711 cylindrical vibration motor preview image 5 6.0 / 8.05 10.3 14.4 1.3 0.9~1.6 90 68 8500 0.80
VZ6SH1B0060711 Z6SH1B0060711 VZ6SH1B0060711 cylindrical vibration motor preview image 5 6.0 / 8.05 10.3 14.4 3.0 2.2~3.6 70 52 10000 1.10
QTY IN STOCK: 4,472
VZ6SL2A0060001 Z6SL2A0060001 VZ6SL2A0060001 cylindrical vibration motor preview image 1 6.0 10.0 14.1 1.3 0.9~1.6 90 65 8500 0.80
VZ6SL2A0060071 Z6SL2A0060071 VZ6SL2A0060071 cylindrical vibration motor preview image 2 6.0 10.0 14.1 1.3 0.9~1.6 90 65 8500 0.80
VZ6SL2A0120001 Z6SL2A0120001 VZ6SL2A0120001 cylindrical vibration motor preview image 1 6.0 10.0 14.1 1.3 0.9~1.6 75 55 8000 0.70
VZ6SL2B0060001 Z6SL2B0060001 VZ6SL2B0060001 cylindrical vibration motor preview image 1 6.0 10.0 14.1 3.0 2.2~3.6 70 50 10000 1.10
VZ6SL2B0060071 Z6SL2B0060071 VZ6SL2B0060071 cylindrical vibration motor preview image 2 6.0 10.2 14.3 3.0 2.2~3.6 70 52 10000 1.10
VZ6SL2B0120001 Z6SL2B0120001 VZ6SL2B0120001 cylindrical vibration motor preview image 1 6.0 10.0 14.1 3.0 2.2~3.8 70 45 11000 1.05
VZ6SL2B0760002 VZ6SL2B0760002 cylindrical vibration motor preview image 1 6.0 10.0 16.3 3.0 2.2~3.6 160 93 12000 2.40
VZ7AJ2B1692081 Z7AJ2B1692081 VZ7AJ2B1692081 cylindrical vibration motor preview image 9 7.0 16.5 23.0 3.0 2.2~3.6 250 180 12000 5.10
VZ7AL2A009000A Z7AL2A009000A VZ7AL2A009000A cylindrical vibration motor preview image 1 7.0 16.5 21.9 1.3 0.9~1.6 65 37 6000 0.85
VZ7AL2A1690001 Z7AL2A1690001 VZ7AL2A1690001 cylindrical vibration motor preview image 1 7.0 16.5 23.0 1.3 0.9~1.6 70 48 5500 1.05
VZ7AL2A1692081 Z7AL2A1692081 VZ7AL2A1692081 cylindrical vibration motor preview image 9 7.0 16.5 24.9 1.3 0.9~1.6 70 48 5500 1.05
VZ7AL2B020208B VZ7AL2B020208B cylindrical vibration motor preview image 9 7.0 16.5 21.7 3.0 2.2~3.6 50 24 7500 1.10
VZ7AL2B1690002 Z7AL2B1690002 VZ7AL2B1690002 cylindrical vibration motor preview image 1 7.0 16.5 23.0 3.0 2.2~3.6 250 180 12000 5.10
QTY IN STOCK: 1,566
VZ7AL2B1692082 Z7AL2B1692082 VZ7AL2B1692082 cylindrical vibration motor preview image 9 7.0 16.5 24.9 3.0 2.2~3.6 250 180 12000 5.10
QTY IN STOCK: 2,988
VZ7AL2B169208T Z7AL2B169208T VZ7AL2B169208T cylindrical vibration motor preview image 9 7.0 16.5 24.9 3.0 2.2~3.6 250 180 12000 5.10
QTY IN STOCK: 1,237
VZ7AL2B1692612 Z7AL2B1692612 VZ7AL2B1692612 cylindrical vibration motor preview image 2 7.0 16.5 23.0 3.0 2.2~3.6 250 180 12000 5.10
QTY IN STOCK: 3,522
VZ7AL2H1690002 Z7AL2H1690002 VZ7AL2H1690002 cylindrical vibration motor preview image 1 7.0 16.5 23.0 1.5 1.0~1.8 370 310 11500 4.10
VZ7AL2H1692082 Z7AL2H1692082 VZ7AL2H1692082 cylindrical vibration motor preview image 9 7.0 16.5 24.9 1.5 1.0~1.8 370 310 11500 4.10
VZ7AV2K0760001L VZ7AV2K0760001L cylindrical vibration motor preview image 1.1 7.0 17.7 23.05 5.0 3.0~5.0 100 78 7000 2.50
Part Number Old P/N (see PCN) Image Config. Type Dia / Hgt (mm) Body L (mm) Overall L (mm) Rated (V) Operating (V) Rated MAX (mA) Typical* (mA) Speed (rpm) Vibe Force (Grms) BUY SAMPLES HERE
VJP08-74D160A JP08-74D160A VJP08-74D160A cylindrical vibration motor preview image 1.1/1.2 8.0 / 6.0 14.5 21.3 4.5 1.5~6.0 230 210 14000 4.80
STOCK: 0
VJP10-35C270M2 VJP10-35C270M2 cylindrical vibration motor preview image 1.1/1.2 10.0 / 8.0 12.5 16.9 4.8 3.0~6.0 175 126 16000 2.60
STOCK: 5,912
VJP12-25F190 JP12-25F190 VJP12-25F190 cylindrical vibration motor preview image 1.1/1.2 12.0 / 10.0 12.0 19.0 3.0 2.0~6.0 350 280 10000 6.00
STOCK: 4,452
VJP12-95J100U VJP12-95J100U cylindrical vibration motor preview image 1.1/1.2 12.0 / 10.0 20.0 28.0 3.0 1.5~4.2 240 200 9600 4.80
VJP16-70E310 JP16-70E310 VJP16-70E310 cylindrical vibration motor preview image 1.1/1.2 15.5 / 12.0 18.6 27.1 7.2 2.5~7.5 180 153 8400 6.40
STOCK: 0
VJQ24-35E400C JQ24-35E400C VJQ24-35E400C cylindrical vibration motor preview image 1.1/1.2 24.4 13.0 25.0 5.0 4.0~8.0 120 69 5100 1.50
VJQ24-35F580C JQ24-35F580C VJQ24-35F580C cylindrical vibration motor preview image 1.1/1.2 24.4 13.0 25.0 5.0 4.0~8.0 150 93 2550 3.30
STOCK: 1,933
VJQ24-35K270B JQ24-35K270B VJQ24-35K270B cylindrical vibration motor preview image 1.1/1.2 24.4 13.0 25.0 5.0 4.0~8.0 650 550 3600 8.40
STOCK: 4,709
VZ30C1B839981A Z30C1B839981A VZ30C1B839981A cylindrical vibration motor preview image 7 3.35 6.95 12.5 3.0 2.3~3.6 85 76 12000 0.45
STOCK: 1,279
VZ30C1T8219731 Z30C1T8219731 VZ30C1T8219731 cylindrical vibration motor preview image 15 3.4 6.7 11.0 2.7 2.3~3.2 85 67 14000 0.42
STOCK: 0
VZ30C1T8219732L Z30C1T8219732L VZ30C1T8219732L cylindrical vibration motor preview image 15 3.4 6.55 11.0 2.7 2.3~3.2 75 57 14000 0.42
STOCK: 10,559
VZ30C1T8460002L Z30C1T8460002L VZ30C1T8460002L cylindrical vibration motor preview image 15 3.0 6.8 10.8 2.7 2.3~3.2 85 67 15000 0.39
STOCK: 44,284
VZ30C1T9870088L Z30C1T9870088L VZ30C1T9870088L cylindrical vibration motor preview image 15 3.5 5.9 12.7 2.3 2.1~3.2 130 107 8500 0.70
STOCK: 1,163
VZ30L4B8790008L Z30L4B8790008L VZ30L4B8790008L cylindrical vibration motor preview image 1 3.15 6.55 10.8 3.0 2.3~3.7 80 58 14000 0.50
STOCK: 445
VZ30L4B8790698L Z30L4B8790698L VZ30L4B8790698L cylindrical vibration motor preview image 17 3.6 7.00 10.8 3.0 2.3~3.7 80 58 14000 0.50
STOCK: 2,399
VZ3TH5B0640081P VZ3TH5B0640081P cylindrical vibration motor preview image 5 3.2 / 4.2 8.4 12.3 3.0 2.5~3.6 80 67 10500 0.75
VZ3TH5B3120066P VZ3TH5B3120066P cylindrical vibration motor preview image 5 3.2 / 4.2 8.4 13.1 3.0 2.5~3.6  40 27 12000 0.60
VZ3TH5B3120076P
blinking new image
VZ3TH5B3120076P cylindrical vibration motor preview image 5 3.2 / 4.2 8.4 13.1 3.0 2.5~3.6  16 12 8500 0.50
VZ3TH8B171700L Z3TH8B171700L VZ3TH8B171700L cylindrical vibration motor preview image 5 2.5 / 2.9 6.6 11.0 2.7 2.3~3.3 100 77 13000 0.40
STOCK: 429
VZ3TL2B3120033P
blinking new image
VZ3TL2B3120033P cylindrical vibration motor preview image 1 3.2 / 3.2 8.15 12.85 3.0 2.5~3.6  16 12 8500 0.50
VZ3TL2B3120034P
blinking new image
VZ3TL2B3120034P cylindrical vibration motor preview image 17 3.2 / 3.8 8.5 13.2 3.0 2.5~3.6  16 12 8500 0.50
VZ3TL5B0640080P VZ3TL5B0640080P cylindrical vibration motor preview image 17 3.2 / 3.8 8.5 12.4 3.0 2.5~3.6 80 67 10500 0.75
VZ3TL5B3120060P VZ3TL5B3120060P cylindrical vibration motor preview image 1 3.2 / 3.2 8.15 12.85 3.0 2.5~3.6  40 27 12000 0.60
VZ3TL5B3120061P VZ3TL5B3120061P cylindrical vibration motor preview image 17 3.2 / 3.8 8.5 13.2 3.0 2.5~3.6  40 27 12000 0.60
VZ43FC1A6730098U VZ43FC1A6730098U cylindrical vibration motor preview image 15 4.85 10.4 15.5 1.3 1.1~1.7 105 94 9000 0.90
STOCK: 658
VZ43FC1B5640005L Z43FC1B5640005L VZ43FC1B5640005L cylindrical vibration motor preview image 15 4.3 5.5 12.0 1.3 1.3~1.6 120 87 9000 0.60
STOCK: 62,280
VZ43FC1B5640007L Z43FC1B5640007L VZ43FC1B5640007L cylindrical vibration motor preview image 15 4.3 7.5 12.0 3.0 2.5~3.4 100 77 10000 0.65
STOCK: 6,506
VZ43FM1B8230001L Z43FM1B8230001L VZ43FM1B8230001L cylindrical vibration motor preview image 15 3.4 6.55 12 3.0 2.3~3.6 85 67 12000 0.60
STOCK: 4,173
VZ4FC1B0951788U VZ4FC1B0951788U cylindrical vibration motor preview image 15 4.85 7.2 11.0 3.0 2.6~3.6 105 90 10000 0.70
VZ4FC1B1301781 Z4FC1B1301781 VZ4FC1B1301781 cylindrical vibration motor preview image 15 4.85 7.2 10.9 3.0 2.6~3.6 110 87 10000 0.70
STOCK: 0
VZ4KC1B1051202 Z4KC1B1051202 VZ4KC1B1051202 cylindrical vibration motor preview image 4 4.0 11.3 15.6 3.0 2.2~3.6 70 42 14000 1.20
STOCK: 559
VZ4KH1A0031121 Z4KH1A0031121 VZ4KH1A0031121 cylindrical vibration motor preview image 5 4.0 / 5.9 11.4 16.6 1.3 1.1~1.6 85 57 8500 0.85
VZ4KH2B0470653N Z4KH2B0470653N VZ4KH2B0470653N cylindrical vibration motor preview image 5 4.0 / 5.95 11.4 16.2 3.0 2.2~3.6 75 56 11000 1.55
STOCK: 0
VZ4KL2A0030001 Z4KL2A0030001 VZ4KL2A0030001 cylindrical vibration motor preview image 1 4.0 11.0 15.8 1.3 1.1~1.6 85 57 8500 0.85
VZ4KL2A0280001 Z4KL2A0280001 VZ4KL2A0280001 cylindrical vibration motor preview image 1 4.0 11.0 16.9 1.3 1.1~1.6 80 56 10000 0.65
VZ4KL2B0030001 Z4KL2B0030001 VZ4KL2B0030001 cylindrical vibration motor preview image 1 4.0 11.0 15.8 3.0 2.2~3.6 70 52 10500 1.15
VZ4KL2B0030471 Z4KL2B0030471 VZ4KL2B0030471 cylindrical vibration motor preview image 17 4.0 / 5.0 11.8 16.6 3.0 2.2~3.6 70 53 10500 1.30
STOCK: 967
VZ4KL2B0280001 Z4KL2B0280001 VZ4KL2B0280001 cylindrical vibration motor preview image 1 4.0 11.0 16.9 3.0 2.2~3.6 70 50 12000 1.05
VZ4KL2B0780012P Z4KL2B0780012P VZ4KL2B0780012P cylindrical vibration motor preview image 17 4.0 / 4.6 11.2 17.0 3.0 2.5~3.6  23 18 7000 0.80
VZ4SH2B0071097N 5 4.0 / 5.8 10.4 14.7 3.0 2.2~3.6 70 45 10000 1.25
VZ4SL2A0270001 Z4SL2A0270001 VZ4SL2A0270001 cylindrical vibration motor preview image 1 4.0 10.0 14.8 1.3 1.1~1.6 80 59 11000 0.65
VZ4SL2A0280001 Z4SL2A0280001 VZ4SL2A0280001 cylindrical vibration motor preview image 1 4.0 10.0 15.9 1.3 1.1~1.6 90 57 9500 0.65
VZ4SL2A0280131 Z4SL2A0280131 VZ4SL2A0280131 cylindrical vibration motor preview image 2 4.0 10.0 15.9 1.3 1.1~1.6 85 57 10000 0.65
VZ4SL2B0270131 Z4SL2B0270131 VZ4SL2B0270131 cylindrical vibration motor preview image 2 4.0 10.0 14.8 3.0 2.2~3.6 60 47 14000 0.70
VZ4SL2B0280001 Z4SL2B0280001 VZ4SL2B0280001 cylindrical vibration motor preview image 1 4.0 10.0 15.9 3.0 2.2~3.6 70 46 12000 1.85
VZ4SL2B0280131 Z4SL2B0280131 VZ4SL2B0280131 cylindrical vibration motor preview image 2 4.0 10.0 15.9 3.0 2.2~3.6 70 50 12000 0.55
VZ4TC2B0640001P Z4TC2B0640001P VZ4TC2B0640001P cylindrical vibration motor preview image 1 4.0 / 4.0 5.5 9.3 3.0 2.4~3.6  22 19 8000 0.40
VZ4TC2B0640002P Z4TC2B0640002P VZ4TC2B0640002P cylindrical vibration motor preview image 17 4.0 / 4.6 5.8 9.6 3.0 2.4~3.6  22 19 8000 0.40
VZ4TC2B0640007P VZ4TC2B0640007P cylindrical vibration motor preview image 6 4.0 / 5.0 5.8 9.6 3.0 2.4~3.6  22 19 8000 0.25
VZ4TH1B0611160L Z4TH1B0611160L VZ4TH1B0611160L cylindrical vibration motor preview image 6 4.0 / 5.8 9.0 13.2 3.0 2.4~3.6 100 80 11000 1.00
STOCK: 1,812
VZ4TH2B0370078L Z4TH2B0370078L VZ4TH2B0370078L cylindrical vibration motor preview image 5 4.0 / 4.5 8.6 12.3 3.0 2.4~3.6  30 20 10000 0.70
VZ4TH5B0191760L Z4TH5B0191760L VZ4TH5B0191760L cylindrical vibration motor preview image 5 4.0 / 4.5 8.6 11.6 3.0 2.4~3.6 85 55 14000 0.80
STOCK: 916
VZ4TH5B1241993L Z4TH5B1241993L VZ4TH5B1241993L cylindrical vibration motor preview image 5 4.0 / 4.9 8.7 11.9 3.0 2.4~3.6 85 55 14000 0.80
STOCK: 1,642
VZ4TH5B1462252 Z4TH5B1462252 VZ4TH5B1462252 cylindrical vibration motor preview image 5 4.0 / 4.9 8.7 12.7 3.0 2.2~3.6  30 21 13000 0.40
VZ4TH5B1462253L Z4TH5B1462253L VZ4TH5B1462253L cylindrical vibration motor preview image 5 4.0 / 4.8 8.7 12.7 3.0 2.4~3.6  30 17 13000 0.70
VZ4TH5B1709181L Z4TH5B1709181L VZ4TH5B1709181L cylindrical vibration motor preview image 5 4.0 / 5.5 8.9 13.4 3.0 2.4~3.6 110 84 10000 1.10
STOCK: 1,506
VZ4TH7B2120042P Z4TH7B2120042P VZ4TH7B2120042P cylindrical vibration motor preview image 6 4.0 / 5.0 8.5 12.3 3.0 2.4~3.6  12 9 8000 0.45
STOCK: 626
VZ4TJ1B0370011L Z4TJ1B0370011L VZ4TJ1B0370011L cylindrical vibration motor preview image 1.1 4.0 / 5.0 8.2 12.2 3.0 2.4~3.6 95 67 14000 0.80
VZ4TL2B0020001 Z4TL2B0020001 VZ4TL2B0020001 cylindrical vibration motor preview image 1 4.0 8.0 12.1 3.0 2.2~3.6 100 73 12000 1.25
VZ4TL2B0020011 Z4TL2B0020011 VZ4TL2B0020011 cylindrical vibration motor preview image 17 4.0 / 5.0 8.0 12.8 3.0 2.2~3.6 100 84 12000 1.00
VZ4TL2B0370032L 1 4.0 / 4.0 8.2 12.1 3.0 2.4~3.6  30 20 10000 0.70
VZ4TL2B0370055L Z4TL2B0370055L VZ4TL2B0370055L cylindrical vibration motor preview image 17 4.0 / 4.5 8.2 12.1 3.0 2.4~3.6  30 20 10000 0.70
STOCK: 174
VZ4TL2B0620043P Z4TL2B0620043P VZ4TL2B0620043P cylindrical vibration motor preview image 1 4.0 / 4.0 8.2 12.8 3.0 2.4~3.6  12 9 8000 0.45
VZ4TL2B0620044P Z4TL2B0620044P VZ4TL2B0620044P cylindrical vibration motor preview image 17 4.0 / 4.7 8.2 12.8 3.0 2.4~3.6  12 9 8000 0.45
STOCK: 526
VZ4TL2B124064X Z4TL2B124064X VZ4TL2B124064X cylindrical vibration motor preview image 17 4.0 / 4.6 8.6 11.6 3.0 2.2~3.6 80 56 15000 1.30
STOCK: 1,262
VZ6CC3A0540001 Z6CC3A0540001 VZ6CC3A0540001 cylindrical vibration motor preview image 11.1 6.0 15.2 20.2 1.3 1.1~1.6 70 43 8500 1.00
VZ6CH1A0082352 Z6CH1A0082352 VZ6CH1A0082352 cylindrical vibration motor preview image 5 6.0 / 8.05 15.3 20.8 1.3 0.9~1.6 80 67 7500 1.10
VZ6CL2A0080001 Z6CL2A0080001 VZ6CL2A0080001 cylindrical vibration motor preview image 1 6.0 15.0 20.6 1.3 0.9~1.6 80 67 7500 1.10
VZ6CL2A0080491 Z6CL2A0080491 VZ6CL2A0080491 cylindrical vibration motor preview image 3 6.0 15.0 20.5 1.3 0.9~1.6 80 67 7500 1.10
VZ6CL2A0540722 Z6CL2A0540722 VZ6CL2A0540722 cylindrical vibration motor preview image 9 6.0 15.0 21.9 1.3 0.9~1.6 70 43 8500 1.00
VZ6DC1A0050091 Z6DC1A0050091 VZ6DC1A0050091 cylindrical vibration motor preview image 4 6.0 12.3 17.3 1.3 0.9~1.6 85 67 8500 0.80
VZ6DC1B0050091 Z6DC1B0050091 VZ6DC1B0050091 cylindrical vibration motor preview image 4 6.0 12.3 17.3 3.0 2.2~3.6 70 57 11000 1.10
VZ6DC1B0730091 Z6DC1B0730091 VZ6DC1B0730091 cylindrical vibration motor preview image 4 6.0 12.3 18.8 3.0 2.2~3.6 90 62 7000 1.30
VZ6DCBB0056091 Z6DCBB0056091 VZ6DCBB0056091 cylindrical vibration motor preview image 4 6.0 12.3 17.3 3.0 2.2~3.6 70 57 11000 1.10
STOCK: 901
VZ6DCBB0735091 Z6DCBB0735091 VZ6DCBB0735091 cylindrical vibration motor preview image 4 6.0 12.3 18.8 3.0 2.2~3.6 90 62 7000 1.30
STOCK: 10,941
VZ6DH2B1501851 Z6DH2B1501851 VZ6DH2B1501851 cylindrical vibration motor preview image 5 6.0 / 7.2 13.1 17.8 3.0 2.2~3.6 75 53 11000 1.20
STOCK: 0
VZ6DH2B1501852 Z6DH2B1501852 VZ6DH2B1501852 cylindrical vibration motor preview image 5 6.0 / 7.2 13.1 17.8 3.0 2.0~3.6  40 23 9500 1.00
VZ6DL2A0050001 Z6DL2A0050001 VZ6DL2A0050001 cylindrical vibration motor preview image 1 6.0 12.0 17.1 1.3 0.9~1.6 85 67 8500 0.80
VZ6DL2A0050441 Z6DL2A0050441 VZ6DL2A0050441 cylindrical vibration motor preview image 2 6.0 12.0 17.1 1.3 0.9~1.6 85 67 8500 0.80
VZ6DL2A0170001 Z6DL2A0170001 VZ6DL2A0170001 cylindrical vibration motor preview image 1 6.0 12.0 17.3 1.3 0.9~1.6 100 72 7000 0.95
VZ6DL2A0170441 Z6DL2A0170441 VZ6DL2A0170441 cylindrical vibration motor preview image 2 6.0 12.0 17.3 1.3 0.9~1.6 100 72 7000 0.95
VZ6DL2A0765217 Z6DL2A0765217 VZ6DL2A0765217 cylindrical vibration motor preview image 9.1 6.0 12.0 24.5 1.3 0.9~1.6 250 175 10000 2.60
VZ6DL2B0050001 Z6DL2B0050001 VZ6DL2B0050001 cylindrical vibration motor preview image 1 6.0 12.0 17.1 3.0 2.2~3.6 70 57 11000 1.10
VZ6DL2B0050441 Z6DL2B0050441 VZ6DL2B0050441 cylindrical vibration motor preview image 2 6.0 12.0 17.1 3.0 2.0~3.8 70 57 11000 1.10
VZ6DL2B0055211 Z6DL2B0055211 VZ6DL2B0055211 cylindrical vibration motor preview image 9.1 6.0 12.0 24.5 3.0 2.2~3.6 70 57 11000 1.10
STOCK: 1,057
VZ6DL2B0170001 Z6DL2B0170001 VZ6DL2B0170001 cylindrical vibration motor preview image 1 6.0 12.0 17.4 3.0 2.2~3.6 85 53 8000 1.80
VZ6DL2B0541192 Z6DL2B0541192 VZ6DL2B0541192 cylindrical vibration motor preview image 17 6.0 / 6.7 12.4 17.4 3.0 2.2~3.6 90 67 11000 2.40
STOCK: 887
VZ6DL2B1501193 Z6DL2B1501193 VZ6DL2B1501193 cylindrical vibration motor preview image 17 6.0 / 6.7 12.4 17.0 3.0 2.0~3.6  40 26 9500 1.00
VZ6DL2H0125215 Z6DL2H0125215 VZ6DL2H0125215 cylindrical vibration motor preview image 9.1 6.0 12.0 24.5 1.5 1.0~1.8 80 35 10200 0.80
VZ6GL2A0050461 Z6GL2A0050461 VZ6GL2A0050461 cylindrical vibration motor preview image 3 6.0 13.5 18.6 1.3 0.9~1.6 70 48 8000 1.00
VZ6SC0A0060081 Z6SC0A0060081 VZ6SC0A0060081 cylindrical vibration motor preview image 4 6.0 10.3 14.4 1.3 0.9~1.6 90 68 8500 0.80
STOCK: 915
VZ6SC0A0150081 Z6SC0A0150081 VZ6SC0A0150081 cylindrical vibration motor preview image 4 6.0 10.3 14.0 1.3 0.9~1.6 80 65 9000 0.65
VZ6SC0B0060081 Z6SC0B0060081 VZ6SC0B0060081 cylindrical vibration motor preview image 4 6.0 10.3 14.4 3.0 2.2~3.6 70 52 10000 1.10
STOCK: 4,006
VZ6SC0B0150081 Z6SC0B0150081 VZ6SC0B0150081 cylindrical vibration motor preview image 4 6.0 10.3 14.0 3.0 2.2~3.6 70 45 10000 1.25
VZ6SC0B0170081 Z6SC0B0170081 VZ6SC0B0170081 cylindrical vibration motor preview image 4 6.0 10.3 15.7 3.0 2.2~3.6 75 48 8000 1.25
VZ6SC3A0060001 Z6SC3A0060001 VZ6SC3A0060001 cylindrical vibration motor preview image 11.1 6.0 10.2 14.3 1.3 0.9~1.6 90 68 8500 0.70
VZ6SCAA0061141 Z6SCAA0061141 VZ6SCAA0061141 cylindrical vibration motor preview image 4 6.0 10.3 14.4 1.3 0.9~1.6 90 68 8500 0.70
VZ6SCAB0061141 Z6SCAB0061141 VZ6SCAB0061141 cylindrical vibration motor preview image 4 6.0 10.3 14.4 3.0 2.2~3.6 70 52 10000 1.10
STOCK: 5,424
VZ6SCAB0171141 VZ6SCAB0171141 cylindrical vibration motor preview image 4 6.0 10.3 15.6 3.0 2.2~3.6 75 48 8000 1.25
VZ6SCAB0761141
blinking new image
VZ6SCAB0761141 cylindrical vibration motor preview image 4 6.0 10.3 16.4 3.0 2.2~3.6 160 120 12000 1.70
VZ6SH1A0060711 Z6SH1A0060711 VZ6SH1A0060711 cylindrical vibration motor preview image 5 6.0 / 8.05 10.3 14.4 1.3 0.9~1.6 90 68 8500 0.80
VZ6SH1B0060711 Z6SH1B0060711 VZ6SH1B0060711 cylindrical vibration motor preview image 5 6.0 / 8.05 10.3 14.4 3.0 2.2~3.6 70 52 10000 1.10
STOCK: 4,472
VZ6SL2A0060001 Z6SL2A0060001 VZ6SL2A0060001 cylindrical vibration motor preview image 1 6.0 10.0 14.1 1.3 0.9~1.6 90 65 8500 0.80
VZ6SL2A0060071 Z6SL2A0060071 VZ6SL2A0060071 cylindrical vibration motor preview image 2 6.0 10.0 14.1 1.3 0.9~1.6 90 65 8500 0.80
VZ6SL2A0120001 Z6SL2A0120001 VZ6SL2A0120001 cylindrical vibration motor preview image 1 6.0 10.0 14.1 1.3 0.9~1.6 75 55 8000 0.70
VZ6SL2B0060001 Z6SL2B0060001 VZ6SL2B0060001 cylindrical vibration motor preview image 1 6.0 10.0 14.1 3.0 2.2~3.6 70 50 10000 1.10
VZ6SL2B0060071 Z6SL2B0060071 VZ6SL2B0060071 cylindrical vibration motor preview image 2 6.0 10.2 14.3 3.0 2.2~3.6 70 52 10000 1.10
VZ6SL2B0120001 Z6SL2B0120001 VZ6SL2B0120001 cylindrical vibration motor preview image 1 6.0 10.0 14.1 3.0 2.2~3.8 70 45 11000 1.05
VZ6SL2B0760002 VZ6SL2B0760002 cylindrical vibration motor preview image 1 6.0 10.0 16.3 3.0 2.2~3.6 160 93 12000 2.40
VZ7AJ2B1692081 Z7AJ2B1692081 VZ7AJ2B1692081 cylindrical vibration motor preview image 9 7.0 16.5 23.0 3.0 2.2~3.6 250 180 12000 5.10
VZ7AL2A009000A Z7AL2A009000A VZ7AL2A009000A cylindrical vibration motor preview image 1 7.0 16.5 21.9 1.3 0.9~1.6 65 37 6000 0.85
VZ7AL2A1690001 Z7AL2A1690001 VZ7AL2A1690001 cylindrical vibration motor preview image 1 7.0 16.5 23.0 1.3 0.9~1.6 70 48 5500 1.05
VZ7AL2A1692081 Z7AL2A1692081 VZ7AL2A1692081 cylindrical vibration motor preview image 9 7.0 16.5 24.9 1.3 0.9~1.6 70 48 5500 1.05
VZ7AL2B020208B VZ7AL2B020208B cylindrical vibration motor preview image 9 7.0 16.5 21.7 3.0 2.2~3.6 50 24 7500 1.10
VZ7AL2B1690002 Z7AL2B1690002 VZ7AL2B1690002 cylindrical vibration motor preview image 1 7.0 16.5 23.0 3.0 2.2~3.6 250 180 12000 5.10
STOCK: 1,566
VZ7AL2B1692082 Z7AL2B1692082 VZ7AL2B1692082 cylindrical vibration motor preview image 9 7.0 16.5 24.9 3.0 2.2~3.6 250 180 12000 5.10
STOCK: 2,988
VZ7AL2B169208T Z7AL2B169208T VZ7AL2B169208T cylindrical vibration motor preview image 9 7.0 16.5 24.9 3.0 2.2~3.6 250 180 12000 5.10
STOCK: 1,237
VZ7AL2B1692612 Z7AL2B1692612 VZ7AL2B1692612 cylindrical vibration motor preview image 2 7.0 16.5 23.0 3.0 2.2~3.6 250 180 12000 5.10
STOCK: 3,522
VZ7AL2H1690002 Z7AL2H1690002 VZ7AL2H1690002 cylindrical vibration motor preview image 1 7.0 16.5 23.0 1.5 1.0~1.8 370 310 11500 4.10
VZ7AL2H1692082 Z7AL2H1692082 VZ7AL2H1692082 cylindrical vibration motor preview image 9 7.0 16.5 24.9 1.5 1.0~1.8 370 310 11500 4.10
VZ7AV2K0760001L VZ7AV2K0760001L cylindrical vibration motor preview image 1.1 7.0 17.7 23.05 5.0 3.0~5.0 100 78 7000 2.50

The “typical current” is the average current from 20 motors selected at random from a given production lot. Copies of the test report showing the data collected for all 20 motors are available upon request.



Mounting Configurations of Vibration Motors

 Config 1 WIRE LEAD TYPE  Config 1.1 WIRE LEAD w. CONNECTOR

Cylindrical Vibration Motors - WIRE LEAD TYPE

Cylindrical Vibration Motors - WIRE LEAD w. CONNECTOR

We can supply this motor with a variety of
different connectors

 Config 1.2 SOLDER TERMINALS

Cylindrical Vibration Motors - SOLDER TERMINALS

 Config 2 WIRE LEAD W. PCB BRACKET  Config 3 WIRE LEAD W. PCB BRACKET

Cylindrical Vibration Motors - WIRE LEAD W. PCB BRACKET

Cylindrical Vibration Motors -WIRE LEAD W. PCB BRACKET

 Config 4 THOUGH-HOLE PCB MOUNTED  Config 5 COMPRESSION SPRING MOUNT

Cylindrical Vibration Motors - THOUGH-HOLE PCB MOUNTED

Cylindrical Vibration Motors - COMPRESSION SPRING MOUNT

 Config 6 COMPRESSION SPRING MOUNT  Config 7 MID-MOUNT PCB SMD REFLOW

Cylindrical Vibration Motors - COMPRESSION SPRING MOUNT

Cylindrical Vibration Motors - MID-MOUNT PCB SMD REFLOW
 Config 9 ENCAPSULATED / ENCLOSED  Config 9.1 ENCAPSULATED-OVER MOLDABLE

Plastic Capsule

Water Resistant Design

Metal Capsule

Overmoldable & Water Proof

 Config 11.1 LIGHT BULB STYLE REAR CONTACT Config 13 COMPRESSION SPRING MOUNT

Cylindrical Vibration Motors - LIGHT BULB STYLE REAR CONTACT

Cylindrical Vibration Motors - COMPRESSION SPRING MOUNT

 Config 14 COMPRESSION SPRING MOUNT Config 15 SURFACE MOUNT TYPE (reflow solderable)

Cylindrical Vibration Motors - COMPRESSION SPRING MOUNT

Cylindrical Vibration Motors - SURFACE MOUNT TYPE (reflow solderable)

 Config 16 SURFACE MOUNT TYPE (reflow solderable)  Config 17 WIRE LEAD WITH RUBBER
GASKET ( RUBBER BOOT )

Cylindrical Vibration Motors - SURFACE MOUNT TYPE (reflow solderable)

Cylindrical Vibration Motors - WIRE LEAD WITH RUBBER GASKET ( RUBBER BOOT )

 Config 18 FLEXIBLE CIRCUIT (FPC)

Cylindrical Vibration Motors - FLEXIBLE CIRCUIT (FPC)

Top
